Excellent performance

A new generation of storage hardware matching flashmemory, providing leading performance solutions

All-around leading specs:PLStor F all-flash uses a multi-core andmulti-threaded high-performance processing platform . RDMA technology is used for high-speedinterconnection between controllers. It supports 32GbpsFC/100Gbps Ethernet and other host interfaces. Theback end uses NVMe over Fabric ( 100Gbps )/SAS 3.0(12Gbps) high-speed interface. , to meetthe needs of high concurrency and low latency access to user databases .

Flexible scalability:supportshigh-speed enterprise-class NVMe SSD drives and SAS SSD drives , a singlesystem can be flexibly expanded to 16 controllers, 12TB cache, and provides millions of IOPS , makingperformance and specifications overall leading.

Flash-orientedsystem architecture design to quickly respond to core business needs

System Architecture forAll-Flash Designs :PLStor Fall-flash memory adoptsinnovative end-to-end deep optimized all-self-developed flash memoryarchitecture design, including intelligent multi-core optimization, resource allocationalgorithm, Cache adaptive algorithm, flash memory intelligent algorithm anddriver, etc. to realize the deep integration of software and hardware in the system, ensuring SSD Onthe premise of long life, it provides faster I/O response, gives full play tothe performance of all-flash storage, ensures that users' key applicationsachieve excellent performance experience, and helps core businesses easilyenter the era of intelligent all-flash storage .

The multi-core and multi-threaded high-performanceprocessing platform ,combined with multi-stream and QoS technology, reduces SSD latency by 30 % , providingusers with higher reliability and higher performance SSD drives .

deep fusion

Equipped with PLStor OSstorage operating system, PLStor Fall-flash further leverages the advantages of integration,providing users with a unified resource pool that is integrated and flexiblyallocated, allowing user data to flow freely, and helping enterprise IT evolveto a cloud architecture.

Fusion of flash memory:Powerleaderhas a comprehensive range of flash memory products that can realizeinterconnection and interoperability of different types, grades, and generationsof flash memory ; through the multi-layered flash memory fusion of data,management, and operation and maintenance, it can achieve millions of IOPS.High performance and low latency, while ensuring the long-term reliability ofSSD.

Convergence of SAN and NAS: PLStor F all-flash can provide SAN and NASservices to meet the needs of flexible business development, improve storageresource utilization, and effectively reduce TCO. The SAN service and NASservice are directly provided by the underlying storage resource pool, which shortensthe access path of storage resources, thus ensuring the industry-leadingperformance and functions of the two services (SAN and NAS).

Convergence of storageresource pools: With built-in heterogeneousvirtualization capabilities, PLStorF all-flash can efficiently take over the storage arrays of othermainstream manufacturers (different grades, different types, different models),and integrate them into a unified resource pool, eliminating data islands,unified management of resources, automation & service orchestration; at thesame time, it can also achieve The migration of third-party devices isinterrupted without any interruption, and the migration operation is automatedand tool-based, reducing time-consuming by an average of 60%.

Convergence of Multiple DataCenters: PLStor Fall-flash provides gateway-free SAN and NAS integrated active- active solutionto achieve business continuity across data centers; supports smooth upgradefrom active- active data centers to 3DC, and provides two -site three-centerbusiness continuity guarantee; can achieve 64:1 Multi-level DC providescentralized disaster recovery and guarantee for data.

Cloud integration:Provide storage hybrid cloud solutions , realize data disaster recovery betweenprivate cloud and public cloud through cloud on-cloud resource coordination anddata flow, and help enterprise storage services to smoothly transform to cloud.

Stableand reliable

Reliable hardware design:Thecontroller, south bridge, network card, and SAS controller are multi-moduleintegrated to reduce failure points , and the reliability of the coreprocessing platform is guaranteed through module -level error recovery, ECC andother RAS technologies ; SSD hard drives are combined with wear leveling and Powerleader'spatented anti-wear leveling algorithm improves the reliability of SSD disks;the intelligent BMC management unit realizes comprehensive management andcontrol of processing platform, memory and other components, and the faultrecovery time is shortened from 2 hours to 10 minutes.

Multi-controller loadbalancing:PLStor Fall-flash memory achieves load balancing amongmultiple controllers, eliminates single points of failure, realizes high systemavailability, and protects stable online services. At the same time, multiplecontrollers can be used to accelerate the same host business concurrently,eliminating the performance bottleneck of a single controller and doubling theperformance.

Unique rapid data recoverytechnology:Using innovative block-levelvirtualization technology, the reconstruction time of 1TB data is reduced from 10hours to 30 minutes. Compared with traditional high-end storage, the risk ofdata failure caused by hard disk failure is reduced by 95%.

Rich data protectionsolutions:Hyper series data protectionsoftware includes snapshot, clone, integrated backup, remote replication,active-active, 3DC and other data protection technologies, which can meet thedata protection needs of users in the system, locally, in different places andin multiple places . Achieve 99.9999% availability to ensure user businesscontinuity and data availability.

SAN and NAS integrated active-activeprotection for core applications :PLStorF all-flash supports SAN and NAS integrated active-active,ensuring high availability of database and file services at the same time. WithHyperMetro AA active-active, load-balancing active-active mirroring andnon-disruptive cross-site takeover can be implemented between storage systems,ensuring zero loss of user key application data and zero business interruption,so that users' core application systems are not troubled by downtime . At thesame time, the gateway-free design can effectively reduce the user'sacquisition cost and deployment complexity. A single set of equipment can besmoothly upgraded to active-active, and can be further extended to two -sitethree-center solutions.

Intelligent management

Intelligent operation andmaintenance management: intelligent remote monitoring,7*24 active monitoring and remote maintenance in the storage cloud, automaticinspection, minute-level fault detection, automatic fault reporting and ordercreation; intelligent fault diagnosis, end-to-end path visualization andperformance from host to storage Correlation analysis to achieve automaticfault location.

Intelligent prediction andevaluation:intelligent risk prediction, basedon multi-dimensional analysis and prediction of harddisk/configuration/capacity/performance, etc., to identify system risks inadvance; intelligent business planning, analysis of host business loadcharacteristics and system capacity prediction, plan system performance andcapacity requirements in advance .
